Mofuta oa li-cabinet tse tharo tsa terata tse tharo

Ho hlahisa mofuta o mong oa khabinete e meraro ea terata ea terata ea terata ea terata ea mohala oa terata ea " E entsoe Chaena, SVg ena e phahameng e phahameng e etselitsoe ho ntlafatsa ts'ebetso ea matla ea matla le ho netefatsa hore ho tsamaisoa ka matla a matla a likopo tsa indasteri. Haeba u batla ho ntlafatsa botsitso ba lits'ebetso tsa matla a hau, kopang qotsulo kajeno!

Romela Lipatlisiso

Tlhaloso ea Sehlahisoa

Letšetso la li-cabinet tse tharo tsa terata tse tharo tsa terata tse tharo tse fanang ka puseletso ea matla ea motlakase ka mohato oa motlakase ka karolo e meraro, litsamaiso tsa Potlako tse tharo. E sebelisa taolo e tsoetseng pele ea DSP + CPD Digital le mofuta oa matšeliso a mararo bakeng sa puseletso e nepahetseng le e potlakileng, ka nako ea morao-rao ea 10ms. Ho kenngoa katoloso ea khabinete ea khabong e netefatsa ts'ebetso e bolokehileng le e tšepahalang ha ho batla litlhophiso tsa indasteri. Bokhoni ba ho tloha ka 15Kvar ho ea 100kvar, e tšoarella mekhahlelo e mengata ea mekhahlelo e meraro ea mekhahlelo e meraro. SVg ena e etselitsoe mekhoa e 380V, ea fana ka tobane le ho etsa lintho tse atlehileng tsa motlakase le matla a motlakase.

Tlhaloso ea mohlala:

Gy	Svg	0.4	50k	/	3L	C
Khoutu ea khoebo	Pakete ea VRAND ea lipalo	Boemo ba voltage 0.22: 220v 0.4: 380v ± 20% 0.5: 500v ± 20% 0.69: 690v ± 20%	Leka-lekaneng (kvar) 5/5 / 35/50/75 / 100Kvar		3L: terata ea metsamao e meraro e meraro	C: cabint

Likaroloana:

● Sebelisa DSP + Lisebelisoa tsohle Digital taolo, theknoloji ea thuto ea bolumeli e merafe ea matla, e tsoetseng pele ho tseba matla a matla a algorithm le pwm.
● Mokhahlelo oa motsoako, o etsang lintho tse tsamaisang motsoako oa mekhabiso e mengata, o nka sebaka ebile ho bonolo ho li hlokomela.
● Moralo o hlophisitsoeng oa li-ducts tse ikemetseng le matloana a ikemetseng li tlisa ts'ebetso e tsitsitseng ea lisebelisoa.
● Etsa puseletso e matla ea matla bakeng sa matla a ho fana ka mokhoa o ikhethileng le matla a sebetsang, le ho rarolla bothata ba ho se kopane ka metsotso e meraro ka nako e le 'ngoe.
● Lebelo le matla la karabelo ho mojaro o sebakeng sa millicond le se ka fihlelang maqeba a matla le a nepahetseng bakeng sa matla a sebetsang a tšusumetso.

Likopo:

Mekha e meraro ea li-cabinet e tharo ea terata e meraro e iketsahalletseng likopo tsa indasteri e hlokang taolo e hlakileng ea litsamaiso tse tharo:

● Khothaletsa ho lokisoa ka mokhoa o meraro ea motsotsoana (litsamaiso tsa terata tse tharo):Ho Ntlafatsa Litšebeletso Matla Kamohelo ea Mekha e meraro ntle le khokahano ea ho se nke lehlakore, le ho ntlafatsa ts'ebetso ea sistimi.
● Taolo ea mekhahlelo e meraro ea mekhahlelo ea mekhahlelo ea mekhahlelo e meraro):Ho ntlafatsa ts'ebetso le katleho ea batho ba bararo ba mekha ea mekhachane ea mekhahlelo e meraro ka terene e meraro.
● Matlafatso ea Matla a Liindasteri tsa indasteri (Wire-mekhahlelo e meraro):Ho fokotsa mocheso le ho netefatsa boleng ba matla a matla a leholimo ho ba maemong a mararo a sebelisa karolo e meraro, abola ea meralo ea meralo.
● Tlhahisoleseling ea Ts'ebetso ea Boitsebiso e Tsoela Pele:Ho ntlafatsa ts'ebetso le botsitso ba lisebelisoa tse tharo ho isa ho tse tharo tikolohong ea lihlahisoa.

Mokhoa oa li-cabinet tse tharo tsa terata tse tharo tse fanang ka matla le ho sebetsa ka thata ho sebelisa boleng ba matla le ho ntlafatsa ts'ebetso ka mohato o meraro, litsamaiso tsa Motlakase tse tharo.

Three-phase three-wire Cabinet-type Static Var Generator

Litekanyetso tsa tekheniki:

	Letoto la 220v	380v letoto la 380v		500v New		690v Series
Bophahamo	<2000m, kaholimo ho 2000m, detete ho latela GB / t3859.2
Mocheso o fetisisang	-20 ~ + 50 ℃
Mongobo o lekanang	≤90%, ha ho na tharollo ka holimo ha mocheso o tlase oa khoeli le khoeli o 25 ℃
Boemo ba tšilafalo	Boemo bona iii ka tlase
Ho sebetsa Voltage	Ac220v ± 20%	Ac380v ± 20%		Ac500v ± 20%		Ac690v ± 20%
Khafetsa	50hz ± 5%
E lekantsoeng e nang le matšeliso	5Kvar	15/35/50/75 / 100Kvar		90kvar		120kvar
Sebopeho sa Grid	L / n	3p3w / 3p4w
Palo ea likarolo tse amanang le ho tšoana	Ulue
Ka kakaretso mochini oa mochini	≥97%
Khafetsa khafetsa	32Khz	16Khz		12.8khz		12.8khz
Khetho ea Ts'ebetso	Matla a sebetsang	PO Were, e ileng ea khahla 'na'
Sekhahla sa matšeliso a matla a motlakase	≥99%	> 95%
Nako e felletseng ea karabelo	<10ms
Lerata	≤60db	≤60db		≤65db		≤65db
Mokhoa oa taolo	2-mokhoa oa Rs485 (li-gprs / WiFi)
Ts'ireletso	Ho imeloa, Software / Hardware ka ho fetelletsa litaba, ho se sebetse hantle, ho hloleha ha motlakase, ho hloleha ho hoholo, ho hloleha ho holofala, jjha		Ho fetella, Software / Hardware ka ho fetelletsa litaba, ho hloleha ha motlakase, ho hloleha ho senyeha, ho thunya ho senyeha hoa potoloho, joalo-joalo.
Mokhoa oa ho kenya	Rack / Wall-Molodi				Rack
Moleng o kenang	Bula ka morao (mofuta oa Rack), o kenang ka holimo (Wall-Molosi oa Wall-Molosi)				Mohala o kenang
Boemo ba ts'ireletso	Ip20

Mohlala & Tlhaloso:

Three-phase three-wire Cabinet-type Static Var Generator

Mohlala oa Sesebelisoa sa Kabinet
Nomoro ea mohlala	Makhotla a busello (Kvar)	Voltage ea sistimi (V)	Boholo (D * w * h)	Mokhoa oa ho futhumatsa
Gy svg-0,4-200k / 4l-c	200	380 ± 20%	800 * 1000 * 2200mm	O ile a khomarela moea
Gy svg-0,4-250k / 4l-c	250	380 ± 20%	800 * 1000 * 2200mm
Gy svg-0,4-300k / 4l-c	300	380 ± 20%	800 * 1000 * 2200mm
Gy svg-0,4-400k / 4l-c	400	380 ± 20%	800 * 1000 * 2200mm
Gy svg-0,5-270k / 4l-c	270	500 ± 20%	800 * 1000 * 2200mm
Gy svg-0,69-360k / 4l-c	360	690 ± 20%	800 * 1000 * 2200mm
